Stainless Steel Steam Autoclave Machine HA-BD
Stainless Steel Steam Autoclave Machine HA-BD
Stainless Steel Steam Autoclave Machine HA-BD
Stainless Steel Steam Autoclave Machine HA-BD

Stainless Steel Steam Autoclave Machine HA-BD

Model:HA-BD

Sterilizing Volume:150L,200L,280L

Features:

1. The steam can’t go through to chamber when the door haven’t close, and the pilot off inform. You can processing dry operate.
2. When the pressure inner over 0, 027MPa. The door be locked and can’t be open.
3. If you not choose the sterile time and start the machine, buzzer sound.
4. If you mistake open the door in the course of start, the jacket value auto off and open the chamber value.
5. Lack water the pilot on, heating and sterile pilot off, the buzzer sound and auto release steam.
6. Overload and leakage protection, when leakage or over current occur, it auto off the power.
7. Temperature controlled not work and the inner pressure over 0.165MPa, the safety value auto open.

Brand:Sada Medical
Shipping Port:Shanghai, Qingdao, Ningbo, Shenzhen, Guangzhou, etc.
Lead Time:20 – 25 working days.

Fully Stainless Steel Steam Sterilization

This unit is ideal equipment for clinics,scientific research institutes and other organizations to sterilize surgical instruments,fabric glassed.culture media etc.

* Full Stainless Steel Steam AutoclaveCertification: CE mark; ISO 13485

* Type: Pressure Steam Sterilizer Equipment.

Full Stainless Steel Autoclave Sterilization Safety Device:

1.The steam can’t go through to chamber when the door haven’t close, and the pilot off to inform. You can process dry operat.
2.When the pressure inner over 0.027Mpa, the door be lock and not be open.
3.If you mistake open the door in the course of start, the jacket valve auto off and open the chamber valve.
4.If you not choose the sterile time and start the machine, buzzer sound.
5.Lack water the pilot on, heating and sterile pilot off, the buzzer sound and auto release steam.
6.Overload and leakage protection, when leakage or over current occur, it auto cut off the power.
7.Temperature controller not work and the inner pressure over 0.165 Mpa, the safety valve auto start open.

Uses of the High PressureFull Stainless Steel Steam Sterilizer:

Medical Instrument Sterilization Autoclave are widely used in microbiology, medicine, podiatry, tattooing, body piercing, veterinary science, mycology, funeral homes, dentistry, and prosthetics fabrication. They vary in size and function depending on the media to be sterilized. Typical loads include laboratory glassware, other equipment and waste, surgical instruments and medical waste.
Sterilization Objects: Unwrapped or Wrapped instruments, Sugircal instruments, Glassware, Liquid , Culture Media, Rubber Material, Gowns, Dressing, Gloves, etc.

After-sale Service: 1 year quality guarantee; Question responsed within 24 hours; Video or photos instruction guide.

Specifications:

Model:HA-BD150,HA-BD200,HA-BD280
Volume:150 Liters 200 Liters 280 Liters

Sterilizing Chamber Volume:
Ø440*H1000 mm,Ø515*H1000 mm,Ø600*H1000 mm

Working Pressure:0.22 Mpa

Working Temperature 134°C

Adjustment of Temperature:40°C-134°C

Adjustment time of Sterilization:0-60 Minutes

Adjustment time of Dry:0-60 Minutes

Heat Average:≤± 2°C
Power:9 KW / AC380V 50Hz,9 KW / AC380V 50Hz,12 KW / AC380V 50Hz

Video of HA-BD Autoclave:



SADA MEDICAL Quality Standards:

ISO 9001:2015 Quality Management Systems
EN ISO 13485:2016 Quality Management System - Medical Devices

CERTIFICATES:



SADA MEDICAL Workshop:


Catalog, Brothures and User Manual Please refer below Link:

https://www.sadamedical.com/pages/catalog-download

Sada Medical is a professional supplier of steam autoclaves, low temperature plasma autoclaves, ethylene oxide sterilizers, dry ovens, consumables, we have exported to all over the world with affordable prices.
