For hospitals, surgical centers, endoscopy units, and laboratories that need a safe, residue‑free sterilization method for heat‑sensitive instruments, the SADA Medical SD‑DS low temperature hydrogen peroxide plasma sterilizer delivers advanced, eco‑friendly performance. Operating at 40°C – 60°C, this H₂O₂ plasma sterilizer is gentle on delicate devices like endoscopes, surgical instruments, ultrasound probes, catheters, and polymer materials – while effectively eliminating all microorganisms[reference:0][reference:1]. With a 68L chamber, rapid cycles (35‑55 minutes), a 7‑inch color LCD touchscreen, and 500‑cycle data storage with export capability, the SD‑DS is the modern choice for low‑temperature sterilization in CSSD, operating rooms, and sterile processing departments[reference:2][reference:3]. The process uses hydrogen peroxide (H₂O₂) which dissociates into water vapor and oxygen – no toxic residues, no aeration required, safe for staff, patients, and the environment[reference:4][reference:5].
Product Video – SD-DS Plasma Sterilizer in Action
⚙️ Why Healthcare Professionals Choose the SD‑DS Plasma Sterilizer
Safe for heat‑sensitive instruments: endoscopes, cameras, catheters, polymer materials – no thermal degradation[reference:6].
Rapid turnaround for busy endoscopy suites and operating rooms – improves instrument availability[reference:7].
H₂O₂ dissociates into water vapor and oxygen – no toxic byproducts, no aeration, safe for staff and patients[reference:8].
PLC intelligent control, real‑time monitoring of sterilization parameters, and one‑touch operation[reference:9].
Records and stores up to 500 sterilization cycles with data export capability – audit‑ready compliance[reference:10].
Medical‑grade HEPA filter removes particles ≥0.3μm, ensuring safe air emission[reference:11].
Overpressure, overheat protection, built‑in humidity & temperature sensors – safe operation under medical‑grade standards[reference:12].
📋 Technical Specifications – SD‑DS Low Temperature Plasma Sterilizer
Engineered for reliable, residue‑free low‑temperature sterilization. The chamber is constructed from high‑quality materials for durability and easy cleaning[reference:13]. Below are the complete specifications.
| Sterilization Method | Hydrogen Peroxide Low‑Temperature Plasma |
| Operating Temperature | 40°C – 60°C[reference:14] |
| Sterilization Cycle | 35 – 55 minutes[reference:15] |
| Sterilization Gas | Hydrogen Peroxide (H₂O₂) |
| Chamber Volume | 68 Liters[reference:16][reference:17] |
| Internal Chamber Dimensions (W×H×D) | 610 × 350 × 320 mm[reference:18][reference:19] |
| External Dimensions (W×H×D) | 750 × 630 × 1495 mm[reference:20][reference:21] |
| Power Supply | AC 220V / 50Hz[reference:22] |
| Power Consumption | 2.6 KVA[reference:23][reference:24] |
| Display | 7‑inch Color LCD Touchscreen[reference:25] |
| Data Storage | 500 Sterilization Records (exportable)[reference:26] |
| Sterilization Pressure | ≤550 Pa[reference:27] |
| Filtration System | 99.5% Medical‑Grade HEPA Filter (≥0.3μm)[reference:28] |
| Certifications | ISO 9001:2015, EN ISO 13485:2016, CE |
🌟 How H₂O₂ Plasma Works: Hydrogen peroxide vapor is introduced into the vacuum chamber, then plasma energy is applied to activate the H₂O₂ molecules. This creates reactive species (free radicals) that destroy microorganisms by attacking cell walls and nucleic acids[reference:29]. After the cycle, the H₂O₂ dissociates into water vapor and oxygen – no toxic residues, no aeration needed[reference:30].
🌟 Ideal for: Flexible and rigid endoscopes, surgical instruments, ultrasound probes, catheters, polymer materials, and any heat‑ or moisture‑sensitive medical devices[reference:31].
🌟 What's included: Plasma sterilizer unit, H₂O₂ sterilization gas system, 7" touchscreen control panel, HEPA filtration system, power cord, user manual.
🏥 Primary Applications
- Hospitals & Clinics – Surgical instruments, endoscopes, ultrasound probes, catheters, dental tools[reference:32]
- Laboratories & Pharmaceuticals – Glassware, precision instruments, GMP‑compliant production tools[reference:33]
- Veterinary & Medical Aesthetics – Surgical tools and beauty equipment[reference:34]
- Endoscopy Centers – Flexible/rigid endoscopes, cameras, light cables
- Operating Rooms & CSSD – Heat‑sensitive surgical devices
✅ Why Choose the SD‑DS?
- Safe for delicate instruments – Low temperature protects against heat damage[reference:35]
- Fast turnaround – 35‑55 minute cycles improve instrument availability[reference:36]
- Eco‑friendly – Only water and oxygen as byproducts[reference:37]
- Full traceability – 500‑cycle data storage with export capability
- Intelligent automation – One‑touch operation with real‑time monitoring[reference:38]
- Superior filtration – 99.5% HEPA filter ensures safe air emission
✅ SADA Medical – Quality & Certifications
SADA Medical Co., Ltd. is a professional manufacturer and supplier of low‑temperature plasma sterilizers, steam autoclaves, and ethylene oxide sterilizers, exporting to over 80 countries worldwide[reference:39]. We are certified under ISO 9001:2015 and EN ISO 13485:2016 (Medical Devices). The SD‑DS hydrogen peroxide plasma sterilizer is factory‑tested with cycle validation reports. Each unit comes with a 12‑month warranty and 24‑hour technical support.
Why customers trust SADA Medical:
- Factory‑direct pricing – no middleman markup
- OEM/ODM customization available[reference:40]
- 12‑month warranty + 24/7 technical support
- Fast worldwide shipping from Shanghai, Ningbo, Qingdao ports
- In‑stock supply, ready for immediate order[reference:41]
📄 Download the full catalog, user manual, and validation guide using the blue button below.
📞 Get a Quote & Free Consultation!
Interested in this product? Contact us today for pricing and more details. Talk directly to our sterilization specialists at Sada Medical Equipment Co., Ltd.
📱 Tel / WhatsApp: +86 18056076519 | 📧 vivian@sadamedical.com | 🌍 sadamedical.com
✔ HS Code 8419200000 – Low‑temperature plasma sterilizers for medical use.
✔ H₂O₂ plasma technology – residue‑free, eco‑friendly, safe for heat‑sensitive instruments.
✔ 68L chamber – suitable for endoscopy suites, ORs, and CSSD.
✔ 35‑55 minute cycles – flexible for routine and complex loads.
✔ 500‑cycle data storage with export capability – full traceability.
✔ 99.5% HEPA filtration – ensures safe air emission.
✔ 12‑month warranty, 24‑hour technical support.
✔ Factory direct sales, OEM/ODM customization available.
✔ Power requirement: AC 220V 50Hz – please confirm your facility's power supply.
