Model: VA-SD
Chamber Capacity: 35L, 50L, 75L, 100L
Class: Class N
Machine Material: Fully stainless steel 304
Display: Digital display
Control: Processor controlled
Door: Hand wheel type door, safety lock door system
Drying Device: USD180 if need
Configuration: 2 pcs stainless steel baskets
Production time: 15 working days
HS Code: 8419200000
Warranty: 12 months
Application range: Hospital, lab, clinic, pharmaceutical factory, research institutions, etc.
Brand:Sada Medical
Product Origin:China
Shipping Port:Shanghai, Qingdao, Ningbo, Shenzhen, Guangzhou, etc.

Features

1.Fully stainless steel structure

2.Hand wheel type of quick-open door structure
3.Door safety lock system
4.Digital display of working status, touch type key
5.Over temperature & over pressure auto-protection
6.Auto discharge the cool air, and steam discharging automatically after sterilization
7.Self-inflating type seal
8.Safe protection of water lacking
9.Easy to operate, safe and reliable
10.With two stainless steel sterilizing baskets
11.Automatically shut off with beep reminding after sterilization
12.Possible to install drying system according request

Safety Device
1. Heater protection
2. Anti-dry heating
3. Safety interlock door
4. Over-temperature protection
5. Over-pressure protection
6. Automatic release safety valve
7. Electric safety protective device.

Technical Specifications

Model VA-SD35 VA-SD50 VA-SD75 VA-SD100
Volume 35 Liters 50 Liters 75 Liters 100 Liters
Sterilizing Chamber Volume Ø318*H450 mm Ø340*H550 mm Ø400*H600 mm Ø440*H650 mm
Working Pressure 0.22 Mpa
Max Working Pressure 0.23 Mpa
Working Temperature 134°C
Adjustment of Temperature 105-134°C
Timer 0-99 min or 0-99 h 59 min
Heat Average ≤± 1°C
Power 2.5 KW/AC220V. 50Hz 3.5 KW/AC220V. 50Hz 4.5 KW/AC220V. 50Hz 4.5 KW/AC220V. 50Hz
Product Dimension 450*450*1010mm 510*470*1130mm 560*560*1120mm 540*560*1250mm
Package Dimension 570*550*1150mm 590*590*1280mm 650*630*1280mm 680*630*1370mm
Gross Weight/Net Weight 72 kg /65 kg 88  kg/ 68 kg 100 kg/ 80 kg 110 kg / 85kg
