1️⃣ Product Introduction
Engineered for centralized sterilization units, the vertical Medical Numerical Control Boiling Disinfector offers large-volume, high-efficiency boiling disinfection for all medical instruments, endoscopes, and luminal tools. It ensures complete compliance with the latest sterilization standards with minimal manual effort.
2️⃣ Product Features & Benefits
-
Intelligent One-Button Operation
Start the complete disinfection cycle—including boiling, oiling, rust prevention, and shutdown—with a single touch. -
Advanced Programmable Control
PLC-based color LCD touchscreen with preset sterilization programs. Displays temperature, working time, consumables used, alarms, and real-time fault diagnostics. -
Smart Memory Function
Automatically records release date, cumulative usage, set boiling time, and temperature—ensuring consistent performance. -
93°C High-Efficiency Boiling Disinfection
Delivers consistent thermal disinfection with real-time A0 value display, fully compliant with WS310.3-2016 standards. -
Comprehensive Safety Protection
Built-in protections against leakage, over-temperature, over-voltage, over-current, and dry operation. -
Automatic Lifting Door (for applicable models)
Hands-free lifting and closing reduce operator fatigue and minimize the risk of accidental scalding. -
Automatic Chemical & Oil Dispensing (Optional)
Precisely meters lubricants and rust inhibitors for extended instrument life. -
Fully Automated Water Management
Supports auto water inlet, drainage, and water level control to ensure smooth operation. -
Infrared Safety System (Lifting Models)
Ensures operator safety with sensor-based door movement and thermal protection. -
Optional Built-in Printer
Easily print sterilization records for traceability and compliance.
3️⃣ Application Scenarios
🏥 Hospital CSSDs & Central Sterile Supply
Designed for high-throughput medical centers, surgical instrument rooms, and central sterile supply departments (CSSDs).
🔧 Suitable Instruments
Used for boiling sterilization of rigid endoscopes, luminal surgical tools, large trays, containers, and reusable OR instruments.
🏗️ Application Environments
- General Hospitals
- Tertiary Care Centers
- Ambulatory Surgical Centers
- Multi-specialty Clinics
🌡️ Why Vertical Type
✔️ Large-capacity tanks for batch disinfection
✔️ Automatic water inlet/drainage system
✔️ Preset programmable PLC control for standardized workflows
♻️ Workflow Example
Post-cleaning instruments from the ultrasonic washer are loaded into the vertical unit for automated boiling, rust prevention, and optional oiling.
4️⃣Why Choose This Product & SADA Medical
🔧 From SADA Medical:
- Proven supplier with installations in 50+ countries
- Comprehensive after-sales support
- Tailored disinfection solutions for diverse facility needs
From the Product:
- Ideal for intensive use with added safety features
- Ergonomics-first design
- Advanced automation ensures consistency and traceability
5️⃣ Technical Specifications
|
Model |
Boiling tank inner dimensions(L*W*H) |
Capacity(L) |
Heating power |
Temperature adjust |
Type |
|
JK-DYJ300 |
300*240*150 |
13L |
4 |
0-99 ºC |
Desktops |
|
JK-DYJ500 |
500*300*150 |
22.5L |
4.5 |
0-99 ºC |
Desktops |
|
JK-DYJ550 |
500*300*200 |
30L |
4.5 |
0-99 ºC |
Desktops |
|
JK-DYJ600 |
600*200*288 |
35L |
6 |
0-99 ºC |
Vertical |
|
JK-DYJ1000 |
600*300*288 |
52L |
10 |
0-99 ºC |
Vertical |
|
JK-DYJ1200 |
600*400*288 |
69L |
12 |
0-99 ºC |
Vertical |
|
JK-DYJ1500 |
700*400*288 |
86L |
13 |
0-99 ºC |
Vertical |
|
JK-DYJ1800 |
700*500*288 |
103L |
14 |
0-99 ºC |
Vertical |
|
JK-DYJ3600 |
1200*600*288 |
207L |
20 |
0-99 ºC |
Vertical |
|
JK-DYJ96 |
600*400*400 |
96L |
13 |
0-99 ºC |
Lifting |
|
JK-DYJ120 |
600*500*400 |
120L |
14 |
0-99 ºC |
Lifting |
|
JK-DYJ144 |
600*600*400 |
144L |
15 |
0-99 ºC |
Lifting |
|
JK-DYJ168 |
700*600*400 |
168L |
16 |
0-99 ºC |
Lifting |
Video showing the appearance and internal structure of the product
Relevant certificates of the product
Catalog, Brothures and User Manual Please refer below Link:
https://www.sadamedical.com/pages/catalog-download
